Our Ferrite Compounds are complex materials which are bonded magnetic materials with thermoplastic resin. Ferrite powder are blended with thermoplastic resin(such as nylon),antioxidants,plasticizers,and other ingredients.Continuous flow compounders are used for intensely mixing the ingredients to form “compound”.The compound is chopped into small granules ready for molding.BGRIMM-MAGMAT ferrite compounds guarantee high magnetic properties and increased tensile strength, provide you excellent cost performance.
◆ Application
●Magnetic stators for fractional horsepower DC motors.
● Multi-pole magnetic rotors for brushless DC and stepped motors.
●Magnetic rolls for laser printers.
● Magnetic actuators for a diverse range of magnetic switches and solenoids.
●Sensors for automotive and industrial applications.
|
P/N |
Mateiral |
Magnetic Properties |
Density |
MFR |
Tensile Strength | |||
|
Br |
Hcb |
Hcj |
(BH)max | |||||
|
mT |
KA/m |
KA/m |
KJ/m3 |
g/cm³ |
g/10min |
MPa | ||
|
SC-4-0.9C |
SrFe+PA6 |
170±10 |
130±10 |
250±20 |
5.5±0.5 |
2.75±0.05 |
200-300 |
≥60 |
|
SC-4-0.9 |
SrFe+PA6 |
185±10 |
145±15 |
230±20 |
7.0±0.5 |
2.85±0.05 |
200-300 |
≥60 |
|
SC-4-1.0D |
SrFe+PA6 |
220±10 |
165±10 |
245±15 |
9.0±0.5 |
3.00±0.05 |
150-250 |
≥60 |
|
SC-4-1.2D |
SrFe+PA6 |
244±10 |
180±10 |
250±15 |
11.5±0.5 |
3.25±0.05 |
150-250 |
≥60 |
|
SC-8-1.5 |
SrFe+PA6 |
255±10 |
180±10 |
245±15 |
12.1±0.5 |
3.30±0.05 |
150-300 |
≥60 |
|
ZH2SB-144 |
SrFe+PA6 |
255±10 |
170±15 |
220±20 |
12.5±0.5 |
3.35±0.05 |
150-250 |
≥60 |
|
SC-3-1.6 |
SrFe+PA6 |
263±10 |
185±10 |
225±15 |
13.5±0.5 |
3.39±0.05 |
200-300 |
≥50 |
|
ZHPA6-1117 |
SrFe+PA6 |
270±10 |
190±10 |
230±20 |
14.2±0.5 |
3.42±0.05 |
250-350 |
≥50 |
|
SC-18-1.9D-J |
SrFe+PA6 |
270±10 |
190±10 |
220±20 |
14.5±0.5 |
3.45±0.05 |
200-300 |
≥50 |
|
SC-18-1.9D-D |
SrFe+PA6 |
270±10 |
190±10 |
220±20 |
14.5±0.5 |
3.45±0.05 |
300-450 |
≥50 |
|
SC-17-1.9D |
SrFe+PA6 |
275±10 |
190±10 |
230±20 |
15.0±0.5 |
3.50±0.05 |
200-350 |
≥50 |
|
SC-26-1120 |
SrFe+PA6 |
285±10 |
195±15 |
225±30 |
16.0±0.8 |
3.54±0.05 |
50-100 |
≥50 |
|
SC-5H-2.0 |
SrFe+PA6 |
286±5 |
195±10 |
230±10 |
16.1±0.4 |
3.55±0.03 |
200-300 |
≥50 |
|
SC-14-2.1B |
SrFe+PA6 |
291±5 |
200±10 |
240±15 |
16.5±0.5 |
3.62±0.03 |
200-300 |
≥50 |
|
SC-14-2.1AL |
SrFe+PA6 |
295±5 |
190±10 |
220±20 |
17.0±0.5 |
3.64±0.05 |
70-170 |
≥50 |
|
SC-14-2.1A |
SrFe+PA6 |
295±5 |
190±10 |
220±20 |
17.0±0.5 |
3.64±0.05 |
260-360 |
≥50 |
|
SC-29-2.2D |
SrFe+PA6 |
300±5 |
185±15 |
220±20 |
18.0±0.5 |
3.80±0.03 |
50-100 |
≥50 |
|
SC-29-2.2C |
SrFe+PA6 |
300±5 |
185±15 |
220±20 |
18.0±0.5 |
3.80±0.03 |
100-200 |
≥45 |
|
SC-2 |
SrFe+PA12 |
270±10 |
195±10 |
230±10 |
14.0±0.5 |
3.40±0.05 |
50-150 |
≥50 |
|
ZHPA12-203 |
SrFe+PA12 |
285±5 |
195±15 |
240±20 |
16.5±0.5 |
3.60±0.05 |
50-100 |
≥45 |
|
SC-PPS-1.5L |
SrFe+PPS |
250±10 |
180±10 |
240±20 |
12.0±0.5 |
3.50±0.05 |
50-100(300℃) |
≥45 |
|
SC-PPS-1.5 |
SrFe+PPS |
250±10 |
180±10 |
240±20 |
12.0±0.5 |
3.50±0.05 |
150-200(300℃) |
≥40 |
|
NdFeB-PPS |
NdFeB+PPS |
470±10 |
320±10 |
710±20 |
38±3 |
4.60±0.05 |
25-75(300℃) |
≥40 |
|
NdFeB-35 |
NdFeB+PA12 |
495±10 |
320±10 |
690±20 |
40±3 |
4.94±0.1 |
400-500 |
≥40 |
